PIOTEC Corporation has independently developed six industrial-grade readers/writers. Utilizing advanced embedded system design and an open architecture, these contactless chip card reader fully support secondary development. They facilitate electrical chip card testing, meeting the demands of smart card manufacturers for high-speed and high-stability production.
These cost-effective readers/writers cater to (pre) personalization and testing of contact smart cards, contactless smart cards, smart card modules, and semiconductor chips. They are well-suited for smart card factories, chip manufacturers, and RFID facilities. The industrial-grade embedded system design ensures efficient, reliable, and secure performance in various applications.
Application areas: Telecom cards, bank cards, ID cards, M2M chips.
Utilizes a Linux embedded operating system, ensuring stability and flexibility for a wide range of applications.
Offers adjustable card writing frequency, supporting speeds of up to 20MHz, providing versatility and efficiency.
Fully supports secondary development, allowing customization and adaptation to specific requirements.
Enables efficient execution of chip production processes, including initialization, personalization, and pre-personalization.
Communication Protocols:
- Supports T=0 protocol with automatic response data retrieval, adjustable (default: disabled)
- Supports T=1 protocol
Electrical Performance Testing:
- Supports open and short circuit testing of pins (adjustable current applied to pins)
- Supports leakage current testing for all pins
- Supports current consumption testing
- Supports voltage-current and current-voltage characteristics testing (V=f(I), I=f(V))
- C7 driving capability testing
- Adjustable Vih and Vil pin voltages
Security Protection: Equipped with ESD protection, short circuit protection, and overcurrent protection features
Operating Modes: Transparent operation of IC card interface chip, with directly modifiable working modes
Address Configuration: IP address set using DIP switch, adjustable to any value between 0 and 255
Operating System: Built-in Linux system, supports secondary development, and allows customization for various applications
